MRCOOL 24,000 Btu 16.5 SEER2 DIY Select Single Zone Ductless Mini Split System w/Install Kit - 208/230V
MRCOOL 24,000 Btu 16.5 SEER2 DIY Select Single Zone Ductless Mini Split System w/Install Kit - 208/230V
Model: DIYS-24-HP-230A11-O
Couldn't load pickup availability
The MRCOOL DIY Select Series is designed to provide efficient, budget-friendly, and reliable comfort for residential applications. This 2-ton system delivers powerful airflow, quiet performance, and simple DIY installation, making it ideal for spacious living areas, basements, and large home additions. Engineered for convenience with a high-efficiency 16.5 SEER2 rating and an included installation kit, it offers dependable year-round heating and cooling performance operating on a robust 208/230V connection.
- Complete DIY Select system including an installation kit for easy setup
- 24,000 BTU (2 ton) capacity designed for spacious areas and heavy load applications
- High-efficiency 16.5 SEER2 rating helps lower utility bills
- Quiet operation enhances occupant comfort in residential spaces
- Wide airflow distribution for consistent room temperatures
- Operates on a standard 208/230V electrical connection
- Washable air filter for convenient and cost-effective maintenance
- Designed for dependable, long-term DIY heating and cooling operation
System & Installation Features:
- Comprehensive installation kit included to simplify the DIY process
- Clean, modern wall-mounted indoor unit blends seamlessly into home interiors
- Durable outdoor condenser built to withstand tough outdoor elements
- Compact equipment footprint for installation flexibility
- User-friendly controls for simplified everyday temperature management
| Model Number (s) | DIYS-24-HP-230A11-O |
| Brand | MrCool |
| SEER | 16.5 |
| Cooling Btu | 24000 |
| Compressor Stage | Inverter |
| Electrical Phase(s) | 1-Phase |
| Decibel Level (dB) | 51.5 |
| Refrigerant Type | R-454B |
| Outdoor Unit Height (Inches) | 26.5 |
| Outdoor Unit Width (Inches) | 35.04 |
| Outdoor Unit Depth (Inches) | 13.46 |
| Parts Warranty (Years) | 1 |
| Compressor Warranty (Years) | 2 |
| AHRI Certificate # | 218004487 |
| UPC # | 633190306487 |
| Heating Btu | 23000 |
| Amp(s) | 20 |
| Voltage | 208/230V |
| Zones | 1 - Zone |
| Total Shipping Weight (lbs.) | 51 |
| Btu | 24000 |
| Indoor Unit Depth (Inches) | 9.21 |
| Indoor Unit Width (Inches) | 42.6 |
| Indoor Unit Height (Inches) | 13.27 |
| HSPF | 8.3 |
| AHRI Certificate # | 218004487 |
| UPC # | 633190306487 |
| Heating Btu | 23000 |
| Amp(s) | 20 |
| Voltage | 208/230V |
| Zones | 1 - Zone |
| Total Shipping Weight (lbs.) | 51 |
| Btu | 24000 |
| Indoor Unit Depth (Inches) | 9.21 |
| Indoor Unit Width (Inches) | 42.6 |
| Indoor Unit Height (Inches) | 13.27 |
| HSPF | 8.3 |
